Technical Specifications
| Transducer type | Condenser (back electret) |
| Operating principle | Pressure gradient |
| Polar pattern | Half-cardioid |
| Frequency response | 25 - 20,000 Hz |
| Open circuit voltage | 1.5 mV/Pa (-56 dBV) |
| Nominal impedance | < 200 Ω |
| Load impedance | ≥ 1 kΩ |
| Max. SPL at 1 kHz | 148 dB [SPL@1% THD] |
| Signal-to-noise ratio | 63 dB [A, RMS] 50 dB [CCIR, Q-Peak] |
| Noise voltage | 1.1 μV [A, RMS], 4.9 μV [CCIR, Q-Peak] |
| A-weighted equivalent SPL | 31.2 dB |
| Polarity | Positive pressure produces positive voltage on pin 2 in relation to pin 3 |
| Wiring | bal. with 3-pin XLR male |
| Connection | XLR, 3-pin, male |
| Power supply | Phantom power P48 (+48 VDC ±4 VDC, 6.8 kΩ±20%, current consumption: < 3.2 mA) P24 (+24 VDC ±4 VDC, 1.2 kΩ±20%, current consumption: < 3.2 mA) P12 (+12 VDC ±4 VDC, 680 Ω±20%, current consumption: < 3.2 mA) |
| Dimensions without connector (L x W x H) | 90 x 86 x 27 mm |
| Weight | 413 g |
