상세스펙
Specifications
| Type | Valve Power Amplifier |
| Valves | V1 : ECC82/12AU7 V2 : ECC83/12AX7 V3, V4, V5, V6 : 845 |
| Operating Mode | Pure Class A |
| Output Stage | Parallel single-ended |
| Output Power | 75W |
| Output Impedance | 8Ω and 4Ω |
| Input Impedance | 47kΩ : Unbalanced 10kΩ : Balanced |
| Outputs | 4Ω bi-wiring : 8Ω bi-wiring |
| Power consumption | 420VA approximately |
| Dimensions | 49 x 77.5 x 28.5 cm (w x d x h) 19.3 x 30.5 x 11.2 inches (w x h x d) |
| Net Weight | 70Kg (155lbs) |
| Main Fuse | 10A slow type (100V-120V) 6.3A Slow type (220V-240V) |
